Plugs and Sockets
MARLIN & TCA LARGE CONNECTORS
Connectors 2 pole Round Pin with Body in ANSI colour code Standard Temperature 205°C continuous 260°C intermittent.
| MARLIN LARGE ROUND PIN PLUG | |
|---|---|
| TCMA1060K | Type K |
| TCMA1060J | Type J |
| TCMA1060T | Type T |
| TCMA1060N | Type N |
| TCMA1060R | Type R/S |
| MARLIN LARGE SOCKET | |
|---|---|
| TCMA1010K | Type K |
| TCMA1010J | Type J |
| TCMA1010T | Type T |
| TCMA1010N | Type K |
| TCMA1010R | Type R/S |
| MARLIN PANEL MOUNT LARGE SOCKET | |
|---|---|
| TCMA1031K | Type K |
| TCMA1031J | Type J |
| TCMA1031T | Type T |
| TCMA1031N | Type N |
| TCMA1031R | Type R/S |
| TCA PANEL MOUNTING LARGE SOCKET | |
|---|---|
| TCMH32K | Type K |
| TCMH32J | Type J |
| TCMH32T | Type T |
| TCMH32N | Type K |
| TCMH32R | Type R/S |
High Temperature 2 Pole with body in Brown colour. 425°C continuous 540°C intermittent.
| MARLIN HIGH TEMP LARGE PLUG | |
|---|---|
| TCMAH1060K | Type K |
| TCMAH1060J | Type J |
| TCMAH1060T | Type T |
| TCMAH1060N | Type N |
| TCMAH1060R | Type R/S |
| MARLIN HIGH TEMP LARGE SOCKET | |
|---|---|
| TCMAH1010K | Type K |
| TCMAH1010J | Type J |
| TCMAH1010T | Type T |
| TCMAH1010N | Type K |
| TCMAH1010R | Type R/S |
| CABLE CLAMP suit Plug or Socket | |
|---|---|
| TCMA1080 | |
| MARLIN TUBE ADAPTOR | |
|---|---|
| TCMA1070125 | 3mm |
| TCMA1070187 | 4.5mm |
| TCMA1070250 | 6mm |
Ceramic 2 pole with body in bone colour up to max 650°C
| TCA CERAMIC PLUG | |
|---|---|
| TCCSPCKA | Type K |
| TCA CERAMIC SOCKET | |
|---|---|
| TCCSJCKA | Type K |
MARLIN & TCA MINI CONNECTORS
Connectors 2 pole Flat Pin with Body in ANSI colour code Standard Temperature 205°C continuous 260°C intermittent.
| MARLIN MINI PLUG FLAT PIN | |
|---|---|
| TCMA1260K | Type K |
| TCMA1260J | Type J |
| TCMA1260T | Type T |
| TCMA1260N | Type N |
| TCMA1260R | Type R/S |
| MARLIN MINI SOCKET | |
|---|---|
| TCMA1210K | Type K |
| TCMA1210J | Type J |
| TCMA1210T | Type T |
| TCMA1210N | Type K |
| TCMA1210R | Type R/S |
| MARLIN PANEL MOUNTING MINI SOCKET | |
|---|---|
| TCMA1231K | Type K |
| TCMA1231J | Type J |
| TCMA1231T | Type T |
| TCMA1231N | Type N |
| TCMA1231R | Type R/S |
| TCA PANEL MOUNTING MINI SOCKET | |
|---|---|
| TCMH132K | Type K |
| TCMH132J | Type J |
| TCMH132T | Type T |
| TCMH132N | Type K |
| TCMH132R | Type R/S |
High Temperature 2 Pole with body in Brown colour. 425°C continuous 540°C intermittent.
| TCA HIGH TEMP MINI PLUG | |
|---|---|
| TCKMPHT | Type K |
| TCJMPHT | Type J |
| TCNMPHT | Type N |
| MARLIN HIGH TEMP MINI SOCKET | |
|---|---|
| TCKMSHT | Type K |
| TCJMSHT | Type J |
| TCNMSHT | Type N |
Ceramic 2 pole with body in bone colour up to max 650°C.
| TCA CERAMIC MINI PLUG | |
|---|---|
| TCCMPCKA | Type K |
| TCA CERAMIC MINI SOCKET | |
|---|---|
| TCCMJCKA | Type K |
| CABLE CLAMP suit Plug or Socket | |
|---|---|
| TCMA1280 | |
| RUBBER BOOT | |
|---|---|
| TCRBS | PAIR |
MARLIN STRIP PANELS
Type K stocked, other calibrations available on request. High temperature versions also available
| Model No. | No. of Circuits | No. of Rows | External Dimensions L x H mm |
|---|---|---|---|
| TCMA10322K | 2 | 1 | 38 x 45 |
| TCMA10324K | 4 | 1 | 76 x 45 |
| TCMA10326K | 6 | 1 | 115 x 45 |
| TCMA10328K | 8 | 1 | 152 x 45 |
| TCA103212K | 12 | 1 | 229 x 45 |
TCA STRIP PANELS
Laser cut stainless steel panel supplied as kit with sockets and screws.
Large Socket Panels available from stock in K, J, T, N, R/S
* Specify Calibration
| No. of Circuits | No. of Rows | External Dimensions L x H mm | Model |
|---|---|---|---|
| 4 | 1 | 120 x 80 | TCSPL4* |
| 6 | 1 | 140 x 80 | TCSPL6* |
| 8 | 1 | 200 x 80 | TCSPL8* |
| 12 | 1 | 275 x 80 | TCSPL12* |
Mini Socket Panels available from stock in K, J, T, N, R/S
* Specify Calibration
| No. of Circuits | No. of Rows | External Dimensions L x H mm | Model | Price Each |
|---|---|---|---|---|
| 4 | 1 | 105 x 60 | TCSPM4* | |
| 6 | 1 | 135 x 60 | TCSPM6* | |
| 8 | 1 | 175 x 60 | TCSPM8* | |
| 12 | 1 | 255 x 60 | TCSPM12* |
